Manual, Bandsaw Machine
HINGED TYPE/ CIRCULAR BLADE / FASTER PRODUCTION
Manual Metal Cutting Bandsaw Machines are the most preferred option amongst our different options in metal cutting machines because of its cost effectiveness, almost no maintenance & easy operation. It also gives reasonably good production with high speed rate cutting.
Product Specifications
| >Model | ABL-1HS | ABL-251HS | ABL-2HS | ABL-3HS | ABL-4HS | ABL-5HS |
|---|---|---|---|---|---|---|
| ROUND CUTTING CAPACITY | 200 | 250 | 315 | 350 | 400 | 450 |
| SQ. CUTTING CAPACITY | 175 x 175 | 250 x 250 | 275 x 275 | 300 x 300 | 400 x 400 | 450 x 450 |
| RECTANGLE CUTTING CAPACITY | 220×100 / 200×150 | 250 x 175 | 300 x 250 | 400 x 200 | 450 x 350 | 500 x 350 |
| BLADE SIZE | 3000x27x0.9 | 3000x27x0.9 | 3760x27x0.9 | 4100x34x1.1 | 4420x34x1.1 | 4570x34x1.1 |
| MAIN MOTOR | 1 | 1.5 | 2 | 2 | 2 | 2 |
| APPROX. WEIGHT (KG) | 350 | 390 | 780 | 840 | 950 | 1050 |
Standard Accessories
- Elec Motor
- Push Button On/Off Switch
- Job Stopper
- Coolant Pump
- Auto Cut Off System
- Wire Brush for Blade Cleaning
- Blade Guard
- Foundation Bolt Kit
- Instruction & Maintenance Manual
Optional Accessories
- Extra Blades
- Machine Light
- Mechanical Job Resting Stand
- Mechanical Job Feeder
- Extra Wire Brush
- Chip Collection Trolley
