T-Slotted – Pallet Table
T-SLOTTED – PALLET / MACHINE TABLE
Cast Iron T-Slotted Machine Table / Pallet Table or Sub Table are being used in various machine tools for mounting of jobs while machining or for quick change over of similar jobs for improving machine utilization time.
T-slotted angle plates manufactured completely in house, with world class manufacturing facility equipped with CNC machines, starting from Design, Casting, Machining and till finish and packing to ensure product quality, with international standards like IS and DIN having Cored and ribbed construction, Cast Iron of grade starting from FG 200 (as per IS 210) OR GG-20 to FG-300 OR GG-30 (or higher) having hardness minimum 160 BHN.
Product Specifications
Machine Tables or Pallet Tables shall be manufactured in various sizes starting from 400x400mm to 5000 x 3000mm or even higher as may be required.
Note: * Other sizes can be manufactured as per requirement.
* Special feature can be added to Machine tables as per requirement of customer.
Salient Features
- Profiles: Generally provided with T-slots sizes 14, 18, 22, 28, 36 or 42 mm conforming to IS:2013 / DIN 650 in tolerance from H12 to H7. Holes, square slots, guiding slots or other profiles on top as well as sides may be provided as per requirement of customers.
- Stress Relieving: Machine Tables shall be manufactured with castings duly stress relieved, after rough machining to prevent distortion.
- Flatness Accuracy: Grade I, II or III as per DIN-876 OR as per IS.
- Surface Finish: CNC finish or Hand Scrapped finish can be provided as per requirement.
- Mounting Provision: Machine tables or pallet tables shall be provided with suitable mounting provisions as per requirement of customer.
